Engine Type

YX™, Single Cylinder, 4 Stroke, Air / Oil Cooled

Displacement

140 cc

Bore x Stroke

55 mm x 59 mm

Rated Output

12 hp @ 8,500 rpm

Fuel Supply

Mikuni® Carburetor, 26 mm

Ignition

CDI

Starter

Kick

Transmission

4-up Manual

Front Suspension

Rebound / Compression Adjustable Forks, Inverted

Rear Suspension

290 mm Spring Pre-load & Rebound Adjustable Shock, 1,000 pounds/inch

Front Brake

Disc

Rear Brake

Disc

Front Wheel / Tire

Steel / 60/100 - 14

Rear Wheel / Tire

Steel / 80/100 - 12

Frame

Double Bar Steel Frame w/ Sub-frame

Swingarm

Steel, "Straight" Type

Wheelbase

48 inches

Seat Height

32 inches

Ground Clearance

12 inches

Fuel Tank

1.45 gallons

Weight

157 pounds

L x W x H

66 x 29.5 x 43 inches

30-day (Parts Only) Limited Warranty Coverage
