Designed for adult-supervised riders ages 6 and older

Keyed ignition and remote, tether-type engine-stop switch

Adjustable throttle limiter controls speed

Easy electric starting, plus backup recoil starter

Smooth-running CVT automatic transmission

Compact, 49cc, four-stroke, single-cylinder, air-cooled engine has been designed for durability and low maintenance.

Efficient, push-rod valve train lets the engine operate quietly. Easy-access oil filter and filler cap simplify service.

Clean-burning, four-stroke engine complies with Environmental Protection Agency (EPA) emissions regulations.

Includes an easy electric starting system plus a standard back-up recoil starter.

Smooth-running CVT automatic transmission provides easy operation and allows the rider to focus on riding instead of shifting.

A keyed ignition switch lets grown-ups decide when the action begins and ends.

Simple screw-type throttle limiter allows adult supervisors to limit the maximum power delivery to suit the rider's ability.

Remote, tether-type engine stop switch allows adult supervisors to instantly shut down the engine when necessary.

Spark-arrestor equipped muffler is environmentally friendly, yet has a pleasant exhaust note.

Suitable capacity 0.7-gallon (2.7-liter) fuel tank for long riding time combined with a vacuum fuel petcock that automatically stops fuel flow when the engine’s not running.

Child-size (Y-6) controls allow easy operation.

Strong, high-rigidity steel frame is sturdy and compact.

Independent swingarm front suspension with coil-over shock absorbers and a single-shock rear suspension provide long wheel travel for a smooth, comfortable ride.

Large-diameter, semi-sealed front drum brakes and single fully-sealed rear drum brake provide strong braking performance.

Modern styling with full floorboards and a big Quad look also features brilliant yellow bodywork with black and red graphics.

Faux headlamp on front fender mimics the sporty look of the QuadSport Z400.

One-piece, seven-inch wheels with tubeless tires provide a smooth comfortable ride.

Low seat height of just 21.1 inches makes it easy for the rider to get on the ATV and operate it with confidence.

Suzuki T-shaped seat design is similar to the QuadSport Z400’s for smooth weight transition and a comfortable ride. The seat is easy to remove for service. Textured seat cover complements the ATV’s graphics package.

Competition-inspired bodywork and Suzuki Champion Yellow color scheme.

12-month limited warranty is double the length of most other youth ATV warranties. Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).*

*Subject to separate coverage for certain parts and the exclusions and limitations described in the New ATV Limited Warranty.

A variety of Genuine Suzuki Accessories for QuadSport owners are available, including a large selection of Suzuki logo apparel.

Minimum age: 6 years old.

ATVs are not toys. Serious injury or death can result from improper use of ATVs. Your youngster’s safety will depend on you taking a "Safety First" approach to ATV riding. The QuadSport Z50 may be used only by those aged 6 and older. Always supervise riders under the age of 16. All other Suzuki ATVs may be used only by those aged 16 and older. Even though your child may be the right age, you need to be sure that he or she has the size, strength, skills, and judgment to operate the ATV safely. The SVIA publication "Parents, Youngsters & ATVs" (included with products and available through your dealer) contains guidelines that can help you determine if your child is ready to ride an ATV.

This model is not eligible for sale in California per California Air Resource Board (CARB) regulations.

Engine

49cc, 4-stroke, air-cooled, single cylinder

Bore x Stroke

36.0 mm x 48.6 mm (1.417 in. x 1.913 in.)

Compression Ratio

8.4:1

Fuel System

Mikuni VM13, single carburetor

Starter

Electric and back-up recoil

Lubrication

Wet sump

Transmission

CVT automatic

Clutch

Dry shoe, automatic, centrifugal type

Driven Wheels

2WD

Final Drive

Chain, DID 415, 82 links

Suspension Front

Independent, swing axle, coil spring, oil damped

Suspension Rear

Swingarm type, coil spring, oil damped

Brakes Front

Twin drum brakes

Brakes Rear

Single drum brake

Tires Front

AT16 × 8-7, tubeless type x 2

Tires Rear

AT16 × 8-7, tubeless type x 2

Fuel Tank Capacity

0.7 US gal. (2.7 L)

Color

Champion Yellow No. 2

Ignition

Electronic ignition (CDI)

Headlight

N/A

Tail Light

N/A

Overall Length

1270 mm (50.0 in.)

Overall Width

760 mm (29.9 in.)

Overall Height

765 mm (30.1 in.)

Wheelbase

830 mm (32.7 in.)

Ground Clearance

120 mm (4.7 in.)

Seat Height

535 mm (21.1 in.)

Curb Weight

79 kg (174 lb.)

Warranty

12-month limited warranty

Extension

Longer coverage periods with other benefits are available through Suzuki Extended Protection (SEP)
